The auxiliary cable is used in supervisory electrical equipment and station control circuits, in light, ordinary or heavy duty industry where power distribution device is needed to transmit control signals or measure signal operations.
STANDARD:
IEC 60227-7
VOLTAGE GRADE: 300/500 V
CONSTRUCTION DESIGN:
Conductor: Flexible, Plain anealed Copper, Class 5, IEC 60228
Insulation material: PVC, PVC/D to IEC 60227-1
Insulation color: Black with number print
Binder: Polyester or Non woven tape
Sheath: PVC, ST-9, IEC 60227-1
Sheath Color: Black, other colors available upon request
Cable marking: MEGHNA STAR CABLES Flexible Control 5*1.0 (sq.mm) 300/500 V
